TAMRON M117FM12 1/1.7" 12mm F/2.4-16 Manual Iris FA and Machine Vision Lens C Mount

FA and Machine Vision Lenses M117FM12 Imager Size 1/1.7" Focal Length 12mm Aperture Range F/2.4-16 Iris Manual Iris SPECIFICATIONS Focus angle : 71.4deg IRIS angle : 52.8deg Model No. M117FM06 Imager Size 1/1.7" Mount Type C Focal Length 12mm Aperture Range F/2.4 - F/16 Field of View Angle (Horizontal x Vertical) 1/1.7" 34.3° x 25.9° 1/1.8" 33.7° x 22.9° 1/2" 29.3° x 22.1° 1/3" 22.1° x 16.6° Focus Range 0.1m - ∞ ( Recommended Shooting Distance 0.3m ) Operation Focus Manual w/lock Iris Manual w/lock Filter Size M34 P=0.5 Wave Length Visible Light TV Distortion -1.02%(*) Weight 50g Operating Temperature -20°C - +60°C * Design Value * Specificotions subjected to change without ony notice.
