TP-LINK TL-WVR300 300M wireless VPN Router 5 ports with machine capacity 30 manage 10 APs
Brand: TP-LINK
Model: TL-WVR300
Dimensions: 126mm x 209mm x 26mm
2 10/100M WAN ports, 3 10/100M LAN ports 2x2 MIMO architecture, wireless transmission rate up to 300Mbps IPSec VPN、PPTP VPN、L2TP VPN Internet behavior management (application restriction, URL filtering, URL filtering, page security, access control list) ARP protection, attack protection, intelligent bandwidth control, and connection limit Support TP-LINK business cloud APP remote view / management port 2 10/100M RJ45 WAN ports 3 10/100M RJ45 LAN ports Wireless rate 300Mbps antenna 2 external detachable 5dBi high gain omniDirectional antenna 2x2MIMO Indicator light Per port: Link/Act Per device: PWR, SYS, WLAN Dimensions 209(w)x126(D)x26(H) mm Input power 100~240V AC,50/60Hz Cooling method Thermally conductive silicone + natural heat dissipation Use environment Operating temperature:
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| port | 2 10/100M RJ45 WAN ports 3 10/100M RJ45 LAN ports |
| Wireless rate | 300Mbps |
| antenna | 2 external detachable 5dBi high gain omniDirectional antenna 2x2MIMO |
| Indicator light | Per port: Link/Act Per device: PWR, SYS, WLAN |
| Dimensions | 209(w)x126(D)x26(H) mm |
| Input power | 100~240V AC,50/60Hz |
| Cooling method | Thermally conductive silicone + natural heat dissipation |
| Use environment | Operating temperature: 0°C~40°C, operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C, storage humidity: 5%~90%RH non-condensing |
| Network protocol | TCP/IP、DHCP、ICMP、NAT、PPPoE、SNTP、HTTP、DNS、H.323、SIP、DDNS |
| Access method | Dynamic IP, static IP, PPPoE, L2TP, PPTP |
| LAN port settings | DHCP server LAN port IP settings |
| MAC address setting | LAN / WAN port MAC address modification, WAN port MAC address cloning |
| Switch settings | Port statistics, port monitoring, port traffic limit Port Vlan |
| wireless function | SSID broadcast Support up to 4 Multi-SSID WDS wireless bridges Support WPA, WPA2, WPA-PSK, WPA2-PSK wireless encryption Inter-SSID isolation, AP internal isolation Wireless MAC address filtering |
| Transmission control | One-to-one NAT mapping, multi-segment NAT virtual server port trigger FTP ALG, H.323 ALG, SIP ALG, IPSEC ALG, PPTP ALG IP bandwidth control, connection number control, flow/connection number monitoring Maximum concurrent connections: 10000 Static routing |
| ARP protection | Support ARP scanning, ARP list, free GARP, support up to 50 IP MAC binding |
| Attack protection | Anti-DoS, Scanning, and Suspicious Packets |
| Access control | Support setting MAC address filtering black and white list Website filtering, URL filtering and access control list Support for prohibiting page submission and filtering specified file extension types |
| Application control | IM restrictions: QQ/Web QQ/MSN/ Fetion/Alibaba/Skype P2P restrictions: Thunder/Thunderbolt/bit comet/eMule/QQLive/PPStream/PPTV financial software restrictions: Great Wisdom/Analyst/Tonghuashun/Qianlong/ Compass/Star of Securities/China Merchants Securities/Guangfa Securities Game Restrictions: QQ Games/Thunder Games/Lianzhong World/Huofang Platform/Fantasy Westward Journey/World of Warcraft/Run Kart/Happy Farm/QQ Farm Basic Application Restrictions: http Submit/http/ https/mms/rtsp proxy limitation: http proxy/socks4 proxy/socks5 proxy QQ/MSN black and white list application feature database upgrade |
| VPN | 5 IPsec VPN tunnels 10 L2TP VPN tunnels 10 PPTP VPN tunnels |
| system service | Peanut shell dynamic DNS UPnP service |
| Management and maintenance | Chinese Web network management, CLI management, remote management Configuration backup and import configuration System software upgrade Interface traffic statistics, IP traffic statistics Online detection, ping, tracert diagnostic tool System logs |
