TP-LINK TL-SH1452 gigabit uplink unmanaged switch 48GE 4SFP+ iron shell layer 2

Brand: TP-LINK

Model: TL-SH1452

Dimensions: 440mm x 220mm x 44mm

48 10/100/1000M adaptive RJ45 ports, 4 10G SFP+ fiber module expansion slots All ports have wire-speed forwarding capabilities Support port auto flip (Auto MDI / MDIX) function Plug and play, can be racked TL-SH1452 is a 10 Gigabit uplink unmanaged Ethernet switch product independently developed by TP-LINK, providing 48 10/100/1000M RJ45 ports and 4 10 Gigabit SFP+ fiber module expansion slots, with wire-speed forwarding capability per port . Port performance Provide 48 10/100/1000M adaptive RJ45 ports and 4 10G uplink SFP+ optical fiber module expansion slots, all ports can realize wire-speed forwarding Each port supports MDI / MDIX automatic rollover and duplex / rate auto-negotiation; Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control. Simple to use

Product Features

48 10/100/1000M adaptive RJ45 ports, 4 10G SFP+ fiber module expansion slots
All ports have wire-speed forwarding capabilities
Support port auto flip (Auto MDI / MDIX) function
Plug and play, can be racked

TL-SH1452 is a 10 Gigabit uplink unmanaged Ethernet switch product independently developed by TP-LINK, providing 48 10/100/1000M RJ45 ports and 4 10 Gigabit SFP+ fiber module expansion slots, with wire-speed forwarding capability per port .

Port performance

Provide 48 10/100/1000M adaptive RJ45 ports and 4 10G uplink SFP+ optical fiber module expansion slots, all ports can realize wire-speed forwarding

Each port supports MDI / MDIX automatic rollover and duplex / rate auto-negotiation;

Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control.

Simple to use

19-inch standard rack installation, plug and play, no management required; dynamic LED indicators provide simple working status prompts and troubleshooting methods

Technical Specifications

Property Description	Property Value
Network Standard	IEEE 802.3 、IEEE 802.3 i、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3 z,IEEE 802.3x
port	48 10/100/1000Mbps RJ45 ports 4 10 Gigabit SFP+ fiber module expansion slots
Indicator light	1 Speed/Link/Ack indicator per port 1 Power indicator per device
performance	Store and Forward Support 16K MAC address table depth
Use environment	Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90%RH, non-condensing Storage humidity: 5%~90%RH, non-condensing
Input power	100-240V~ 50/60Hz
Dimensions (L x W x H)	440mm x 220mm x 44mm
