TP-LINK TL-FW5600 Enhanced Firewall

Brand: TP-LINK

Model: TL-FW5600

Dimensions: 250mm x 158mm x 44mm

Dual-core 64-bit network-specific processor, single-core frequency 1GHz, 1GB DDRIV high-speed memory 5 10/100/1000M RJ45 port Supports configuring security policies, audit policies, bandwidth policies, ALG policies, etc. Support multiple security protection functions, defend against ARP spoofing, ARP attacks, DDoS attacks, network scanning, suspicious packet attacks, etc. Support expanded integrated DPI deep security (intrusion defense, anti-virus, file filtering, malicious domain remote query, application behavior control) Supports rich policy objects (security zones, addresses, users, services, websites, security profiles, intrusion prevention, audit profiles, etc.) Support rich network functions, static routing, policy routing, intelligent balance, VPN (IPSec/PPTP/L2TP VPN), DDNS, etc.

Product Features

Dual-core 64-bit network-specific processor, single-core frequency 1GHz, 1GB DDRIV high-speed memory
5 10/100/1000M RJ45 port
Supports configuring security policies, audit policies, bandwidth policies, ALG policies, etc.
Support multiple security protection functions, defend against ARP spoofing, ARP attacks, DDoS attacks, network scanning, suspicious packet attacks, etc.
Support expanded integrated DPI deep security (intrusion defense, anti-virus, file filtering, malicious domain remote query, application behavior control)
Supports rich policy objects (security zones, addresses, users, services, websites, security profiles, intrusion prevention, audit profiles, etc.)
Support rich network functions, static routing, policy routing, intelligent balance, VPN (IPSec/PPTP/L2TP VPN), DDNS, etc.
Multiple administrator roles, fine-grained authority management

Technical Specifications

Property Description	Property Value
port	4 10/100/1000M RJ45 port 1 10/100/1000M RJ45 management port 1 USB storage port 1 console port 1 Micro SD card slot
processor	dual-core 64-bit MIPS network-specific processor, single core frequency 1GHz
RAM	DDRIV 1GB
FLASH	32MB NOR+512MB NAND
Indicator light	port: LINK / ACT, USB, Micro SD devices: PWR, SYS, Cloud
Dimensions	250 x 158 x 44 mm
Input power	100~240V AC,50/60Hz
Cooling method	Natural heat dissipation
Use environment	operating temperature: 0°C ~ 40°C, Working humidity: 10% ~ 90% RH does not condense storage temperature: -40°C ~ 70°C, storage humidity: 5% ~ 90 % RH does not condense
Policy configuration	Security Policy, Audit Policy Bandwidth Policy (Bandwidth Control, Connection Limit, Connection Monitoring) NAT Policies (NAPT, One-on-One NAT, Virtual Server, NAT-DMZ, UPNP) ALG Policy (FTP ALG, H.323 ALG, PPTP ALG, SIP ALG)
Strategy Object	security zone, address, user, service, website, application, black and white list, intrusion defense security profile (URL filtering, file filtering, application behavior control, mail content filtering, anti Virus) audit profile (HTTP behavior audit, FTP behavior audit, email auditing, IM audit)
Attack protection	support ARP protection, such as ARP spoof, ARP attack support a variety of common attack protection, such as DDoS attack, network scan, suspicious pack attack support Mac Address filtering, blocking access to illegal hosts
Integrated DPI depth security	Support intrusion defense support anti-virus support malicious domain remote query support application behavior identification support Filter file expansion type
Network function	Static route, policy routing intelligent balance VPN (IPSEC / PPTP / L2TP VPN) Dynamic DNS (peanut shell, department Mai, 3322)
System Management	support Chinese web management, remote management support multiple management roles support configuration backup and import support system software upgrade Supports a variety of logs, reports, diagnostic centers, panel status support license management support feature library upgrade
San Dick	memory 64G and 128G, performance parameters U3, V30, Class10
Kingston	memory 64G and 128G, performance parameters U1, A1, V10, Class10
Samsung	memory 64G and 128G, performance parameters U1, Class10
Toshiba	memory 64G and 128G, performance parameters U1, Class10
