TP-LINK TL-GP110 Single-port Gigabit GPON
Brand: TP-LINK
Model: TL-GP110
Dimensions: 106mm x 102mm x 37mm
supporting agreement ITU-T G.984 IEEE 802.3 IEEE 802.3u IEEE 802.3ab Highest rate Downlink: 2500Mbps Uplink: 1250Mbps Operating mode RFC1483(Bridge) interface 1 SC/UPC GPON interface 1 10/100/1000M adaptive RJ45 interface Button Power switch button Reset button Indicator light POWER status indicator PON status indicator LOS status indicator LAN status indicator size 106mm x 102mm x 37mm L x W x H power supply 9V 0.6A power adapter Packaging accessories One GPON terminal TL-GP110 One power adapter One quick installation guide One network cable Use environment Operating temperature: 0°C to 40°C Storage temperature: -40°C to 70°C Operating humidity: 10% to 90% (RH does not condense) Storage humidity: 5% to 90% (RH does not condense)
Technical Specifications
| Property Description | Property Value |
|---|---|
| supporting agreement | ITU-T G.984 IEEE 802.3 IEEE 802.3u IEEE 802.3ab |
| Highest rate | Downlink: 2500Mbps Uplink: 1250Mbps |
| Operating mode | RFC1483(Bridge) |
| interface | 1 SC/UPC GPON interface 1 10/100/1000M adaptive RJ45 interface |
| Button | Power switch button Reset button |
| Indicator light | POWER status indicator PON status indicator LOS status indicator LAN status indicator |
| size | 106mm x 102mm x 37mm L x W x H |
| power supply | 9V 0.6A power adapter |
| Packaging accessories | One GPON terminal TL-GP110 One power adapter One quick installation guide One network cable |
| Use environment | Operating temperature: 0°C to 40°C Storage temperature: -40°C to 70°C Operating humidity: 10% to 90% (RH does not condense) Storage humidity: 5% to 90% (RH does not condense) |
