TP-LINK TL-AP2605GP AC2600 dual-band outdoor high-power wireless AP
11AC dual-band concurrent, the highest wireless rate can reach 2533Mbps Professional outdoor shell design, waterproof and dustproof grade up to IP68, working temperature acceptable -30℃~65℃, adapt to various harsh environments Spectrum navigation to make the load of the two frequency bands 2.4GHz and 5GHz more balanced Linear adjustable power, effectively reducing mutual interference between APs Automatically remove weak signal devices to avoid dragging the entire network and improve wireless network performance Independent hardware protection circuit can automatically recover abnormal AP Passive PoE network cable power supply, flexible deployment Pole/wall installation, flexible and simple Product model TL-AP2605GP Installation method Pole / wall mounting size 310x310x84mm wireless
Product Features |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Product model | TL-AP2605GP |
| Installation method | Pole / wall mounting |
| size | 310x310x84mm |
| wireless | 2.4GHz band: 800Mbps 5GHz band: 1733Mbps |
| port | 2 10/100/1000Mbps RJ45 ports 1 100/1000Mbps SFP interface (recommended to use industrial-grade optical modules with operating temperature above 85°C) 8 N-head antenna interfaces |
| antenna | Provide 8 antenna N heads, support external antenna |
| Antenna coverage angle | Determined by external antenna |
| Indicator light | 1 system indicator 1 SFP indicator 2 RJ45 indicators 2 wireless status indicators |
| Button | 1 RESET button 1 FAT/FIT mode toggle switch |
| power supply | 53.5VDC / 0.7A Passive PoE power supply, power supply distance up to 100M |
| management | FIT AP mode: unified management by TP-LINK wireless controller (AC) FAT AP mode: independent web page management |
| Environmental protection | IP68 dustproof and waterproof |
| Use environment | Operating temperature: -30°C~65°C Operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C Storage humidity: 5%~90%RH non-condensing |
| Recommended coverage distance (open environment) | OmniDirectional recommendation 2.4G: 180 meters; 5G: 300 meters (determined according to external antenna specifications) |
| wireless function | SSID broadcast: Support SSID quantity: 8 (2.4GHz) + 8 (5GHz) Network type: Guest network, employee network Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK User isolation: Isolation between wireless networks, AP internal isolation Wireless MAC address filtering: support whitelist (50) VLAN setting: support SSID and Tag VLAN binding transmit power setting: support 1dBm linear adjustment WDS function: support wireless client number limit: support QoS: WMM kick out weak signal devices, prohibit Weak signal equipment access: support |
| System Management | Device management: All Chinese WEB management System log: support Restore factory settings: support Backup configuration: support Import configuration: support Software upgrade: support Ping watchdog: support |
| Recommended wireless band capacity | 30(2.4G)+55(5G) |
| Maximum wireless belt capacity | 100(2.4G)+100(5G) |
