TP-LINK TL-AP1908GC-PoE/DC AC1900 dual frequency wireless ceiling AP
11AC dual-band concurrent, the highest wireless rate can reach 1900Mbps Professional dual-band antenna to improve the signal quality of the coverage area Spectrum navigation to guide dual-band clients to preferentially connect to the 5GHz frequency band to make the 2.4GHz and 5GHz frequency bands more balanced and ensure network performance Simple ceiling installation, supports 802.3af/at standard PoE, 12VDC power supply Fat and thin, choose different working modes in different environments FIT mode supports automatic RF tuning FIT mode supports intelligent roaming Support centralized management of TP-LINK commercial cloud platform Support TP-LINK business cloud APP remote view / management Product model TL-AP1908GC-PoE/DC Installation method Ceiling / wall mounting size 230*230*60mm
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Product model | TL-AP1908GC-PoE/DC |
| Installation method | Ceiling / wall mounting |
| size | 230*230*60mm |
| wireless | 2.4GHz band: 600Mbps 5GHz band (11AC): 1300Mbps |
| port | 1 10/100/1000M RJ45 port 1 DC port |
| Indicator light | 1 system indicator |
| Button | 1 Reset button 1 FAT/FIT mode toggle switch |
| Power supply | 802.3af/at standard PoE power supply 12V/1.5A DC power supply (no power adapter is shipped from the factory) |
| Maximum machine power consumption | 11.29W |
| management | FIT AP mode: unified management by TP-LINK wireless controller (AC) FAT AP mode: independent web page management |
| Use environment | Operating temperature: 0°C~40°C Operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C Storage humidity: 5%~90%RH non-condensing |
| wireless function | SSID broadcast: Support SSID quantity: 8 (2.4GHz) + 8 (5GHz), support Chinese SSID Network type: Guest network, employee network Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK User isolation: Isolation between wireless networks , AP internal isolation wireless MAC address filtering: support whitelist (100) VLAN settings: support SSID and Tag VLAN binding transmit power settings: support 1dBm linear adjustment wireless client number limit: support QoS: WMM WDS: support spectrum navigation (5G Priority): Support kick out weak signal equipment, prohibit weak signal equipment access: support |
| Maximum number of connectable clients | 64(2.4GHz)+64(5GHz) |
| System Management | Device management: All Chinese WEB management System log: support Restore factory settings: support Backup configuration: support Import configuration: support Software upgrade: support Ping watchdog: support |
