TP-LINK TL-XAP6009GC-PoE/DC AX6000 Dual Band Wi-Fi6 Wireless Ceiling AP(2.5G Port)
Next-generation Wi-Fi 6 (802.11ax) technology 11AX dual-band concurrent, the highest wireless rate can reach 5951Mbps 2.5G network port, support IEEE 802.3bz Ethernet standard, higher speed Internet access Built-in 5dBi omniDirectional antenna, independent RF circuit design, improve signal quality in coverage area The port is hidden in the shell, and the wiring is beautiful Automatic RF tuning to optimize overall performance Fat and thin, choose different working modes in different environments Smart roaming to enhance wireless experience DC, 802.3bt/at PoE and Passive PoE power supply, flexible layout Ceiling/wall-mounted installation, easy maintenance Support centralized management of TP-LINK commercial network cloud platform Product model TL-XAP6009GC-PoE/DC Installation method Ceiling
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Product model | TL-XAP6009GC-PoE/DC |
| Installation method | Ceiling / wall mounting |
| size | Φ390x73mm |
| wireless | 2.4GHz band: 1147Mbps 5GHz band: 4804Mbps |
| port | 1 10/100/1000M/2500Mbps RJ45 port (support IEEE 802.3bz) 1 DC interface |
| antenna | Built-in 5dBi omniDirectional antenna |
| Antenna coverage angle | 360° |
| Indicator light | 1 system indicator |
| Button | 1 RESET button 1 FAT/FIT mode toggle switch |
| power supply | 53.5VDC/0.81A Passive PoE power supply, power supply distance up to 100M IEEE 802.3bt/at standard PoE power supply 12-53.5V DC power supply |
| management | FIT AP mode: unified management by TP-LINK wireless controller (AC) FAT AP mode: independent web page management TP-LINK commercial network cloud platform centralized management |
| Maximum power consumption | 28.6W |
| Use environment | Operating temperature: 0°C~40°C Operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C Storage humidity: 5%~90%RH non-condensing |
| wireless function | SSID broadcast: Support SSID quantity: 8 (2.4GHz) + 8 (5GHz) Network type: Guest network, employee network Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK User isolation: Isolation between wireless networks, AP internal isolation Wireless MAC address filtering: support whitelist (50) VLAN setting: support SSID and Tag VLAN binding transmit power setting: support 1dBm linear adjustment WDS function: support wireless client number limit: support QoS: WMM kick out weak signal devices, prohibit Weak signal equipment access: support |
| System Management | Device management: All Chinese WEB management System log: support Restore factory settings: support Backup configuration: support Import configuration: support Software upgrade: support Ping watchdog: support |
