TP-LINK TL-WDN6280 AC1300 Dual Band Wireless PCIe Network Card
interface PCIe antenna Two external omniDirectional antennas Dimensions 121 mm x 79 mm x 22 mm Use environment Working temperature: 0°C~40°C Storage temperature: -40°C~70°C Humidity: 10% ~ 90%RH No condensation Package Contents AC1300 Dual Band Wireless PCIe Network Card TL-WDN6280 Driver CD User Manual Follow the standard IEEE 802.11ac IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n Transmission rate 11b:1/2/5.5/11Mbps 11g:6/9/12/18/24/36/48/54Mbps 11n:400Mbps 11ac:867Mbps Frequency Range 2.4 ~ 2.4835GHz 5.150~5.250GHz 5.725~5.850GHz Working channel 1 ~ 13 36~48 149~165 Transmit power 20dBm (maximum) Safety features WPA-PSK/WPA2-PSK WPA/WPA2 Operating system support Windows XP/WindowsXP 64 Windows 7/Windows7 64 Windows 8/Windows8 64 Windows 8.1/Windows8.1 64 Windows 10/Windows10 64
Technical Specifications
| Property Description | Property Value |
|---|---|
| interface | PCIe |
| antenna | Two external omniDirectional antennas |
| Dimensions | 121 mm x 79 mm x 22 mm |
| Use environment | Working temperature: 0°C~40°C Storage temperature: -40°C~70°C Humidity: 10% ~ 90%RH No condensation |
| Package Contents | AC1300 Dual Band Wireless PCIe Network Card TL-WDN6280 Driver CD User Manual |
| Follow the standard | IEEE 802.11ac IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n |
| Transmission rate | 11b:1/2/5.5/11Mbps 11g:6/9/12/18/24/36/48/54Mbps 11n:400Mbps 11ac:867Mbps |
| Frequency Range | 2.4 ~ 2.4835GHz 5.150~5.250GHz 5.725~5.850GHz |
| Working channel | 1 ~ 13 36~48 149~165 |
| Transmit power | 20dBm (maximum) |
| Safety features | WPA-PSK/WPA2-PSK WPA/WPA2 |
| Operating system support | Windows XP/WindowsXP 64 Windows 7/Windows7 64 Windows 8/Windows8 64 Windows 8.1/Windows8.1 64 Windows 10/Windows10 64 |
