TP-LINK TL-SL1351 gigabit unmanaged switch 48FE 2GE 1SFP iron shell layer 2
48 10/100M adaptive RJ45 ports, 2 10/100/1000M adaptive RJ45 ports and 1 Gigabit SFP (mini GBIC) fiber module expansion slot, flexible expansion All ports have wire-speed forwarding capabilities Support port auto flip (Auto MDI / MDIX) function Support MAC address self-learning; support full-duplex working mode Standard rack mount, plug and play, no management required TL-SL1351 is a Layer 2 Gigabit uplink unmanaged switch product specially designed by TP-LINK for Internet cafes, enterprises, campuses and smart communities. RJ45 port and 1 Gigabit SFP (mini GBIC) fiber module expansion slot, all ports support wire-speed forwarding and MDI / MDIX automatic rollover function, plug and play, can be racked. Port performance Provide 48 10/100M adaptive RJ45 ports, 2 10/100/1000M adaptive RJ45
Product Features
TL-SL1351 is a Layer 2 Gigabit uplink unmanaged switch product specially designed by TP-LINK for Internet cafes, enterprises, campuses and smart communities. RJ45 port and 1 Gigabit SFP (mini GBIC) fiber module expansion slot, all ports support wire-speed forwarding and MDI / MDIX automatic rollover function, plug and play, can be racked. Port performanceProvide 48 10/100M adaptive RJ45 ports, 2 10/100/1000M adaptive RJ45 ports and 1 Gigabit SFP (mini GBIC) fiber module expansion slot, all ports can realize wire-speed forwarding; Each port supports MDI / MDIX automatic rollover and duplex / rate auto-negotiation; Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control. Energy saving and environmental protectionEnergy-saving technology is used to automatically adjust the signal strength by detecting the length of the network cable and the workload to effectively reduce product power consumption. Simple to use19-inch standard rack installation, plug and play, no management required; dynamic LED indicators provide simple working status prompts and troubleshooting methods |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Network Standard | IEEE 802.3 、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3x |
| port | 48 10/100Mbps RJ45 ports 2 10/100/1000Mbps RJ45 ports 1 independent Gigabit SFP fiber port |
| Indicator light | 1 Link/Ack indicator per port 1 Power indicator per device |
| performance | Store and Forward Support 8K MAC address table depth |
| Use environment | Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90%RH, non-condensing Storage humidity: 5%~90%RH, non-condensing |
| Input power | 100-240V~ 50/60Hz |
| Dimensions (L x W x H) | 440mm x 180mm x 44mm |
