TP-LINK TL-NR700-4C-5G High Performance Full Gigabit Enterprise Router

Brand: TP-LINK

Model: TL-NR700-4C-5G

Dimensions: 227mm x 440mm x 44mm

Quad-core 64-bit network dedicated processor, single-core main frequency 1.2GHz 2GB DDRIV high-speed memory 5 10/100/1000M RJ45 ports, customizable port types Support point-to-point screen projection function Access authentication (Web authentication, SMS authentication, PPPoE server) Multiple VPNs (IPSec / PPTP / L2TP VPN) Online behavior management (application restriction / website filtering / web security) Internal and external network ARP protection and common attack protection Intelligent IP bandwidth management and connection limit port

5 10/100/1000M RJ45 port
1 console port

processor

quad-core 64-bit MIPS network-specific processor, single-core clue 1.2GHz

RAM

DDRⅣ 2GB

FLASH

64MB

Indicator

Product Features

Quad-core 64-bit network dedicated processor, single-core main frequency 1.2GHz
2GB DDRIV high-speed memory
5 10/100/1000M RJ45 ports, customizable port types
Support point-to-point screen projection function
Access authentication (Web authentication, SMS authentication, PPPoE server)
Multiple VPNs (IPSec / PPTP / L2TP VPN)
Online behavior management (application restriction / website filtering / web security)
Internal and external network ARP protection and common attack protection
Intelligent IP bandwidth management and connection limit

Technical Specifications

Property Description	Property Value
port	5 10/100/1000M RJ45 port 1 console port
processor	quad-core 64-bit MIPS network-specific processor, single-core clue 1.2GHz
RAM	DDRⅣ 2GB
FLASH	64MB
Indicator light	Each port: LINK / ACT, Speed Each device: PWR, SYS
Dimensions	440(w)x227(D)x44(H) mm
Input power	100~240V AC,50/60Hz
Cooling method	thermal silicone + natural heat dissipation
Use environment	operating temperature: 0°C ~ 40°C, Working humidity: 10% ~ 90% RH does not condense storage temperature: -40°C ~ 70°C, storage humidity: 5% ~ 90 % RH does not condense
Typical belt load	3000 sets
Network protocol	TCP/IP、DHCP、ICMP、NAT、PPPoE、SNTP、HTTP、DNS、H.323、SIP、DDNS
basic settings	interface setting DHCP server
AP management	AP setting, managed to manage 300 TP-LINK AP wireless network settings wireless client status
Access method	Dynamic IP, Static IP, PPPoE, L2TP, PPTP
Transmission control	Napt One-to-one NAT mapping virtual server FTP ALG, H.323 ALG, SIP ALG, PPTP ALG IP bandwidth control, connection number control, traffic / connection number monitoring maximum concurrent connection number: 1000000 Intelligent balance, special application selection, ISP selection Road, Line Backup Static Routing, Policy Routing, System Routing List
ARP protection	support ARP scan, ARP list, free GARP support IP Mac binding
Attack protection	anti-DOS class, scanning class, suspicious package class, etc., etc., etc., etc., etc., etc., etc., etc., etc., etc., etc.
Access control	Support Setup MAC Address Filter Black and White List Access Control List
Behavior control	Social Software / Video Software / Music Software / Shopping Leisure Software / News Software / P2P Software / Financial Software / Network Game / App Store / Fundamental Application Limits QQ black and white list URL filter web security (prohibition page submission, filter specified file extension type) application feature database upgrade
VPN	IPsec VPN (200 Tunnel) PPTP / L2TP VPN (200 Tunnel)
Certification Management	web authentication, local authentication, RADIUS authentication, one-click Internet access, meet a variety of certification requirements can be customized by custom authentication page, easy to push text, picture advertisement, carry out marketing promotion Free certification policy
system service	Dynamic DNS (Peanut Shell, Komai, 3322) UPNP Service DNS Agent
Management and maintenance	Chinese Web Network Management, Remote Management Configuration Backup and Import Configuration System Software Upgrade Interface Traffic Statistics, IP Traffic Statistics ping, Tracert Diagnostic Tool System Log
Industry application	Peer-to-peer screencast
