TP-LINK TL-NR600-2C-9G-PoE Dual-core multi-WAN Port PoE AC Integrated Gigabit Router

• Dual-core CPU, 512MB DDRIII high-speed memory, strong performance
• 9 Gigabit Ethernet ports, 1WAN+3WAN/LAN+5LAN
• 3 WAN/LAN ports and 5 LAN ports all support standard PoE power supply, single port output power 30W, output power of the whole machine up to 240W
• IPSec/PPTP/L2TP VPN, remote communication is more secure
• Web authentication, SMS authentication, PPPoE server
• Internet behavior management (mobile APP control/desktop application control/website filtering/behavior audit)
• Built-in AC function, can manage 50 TP-LINK enterprise APs
• Load balancing and line backup
• Internal and external network ARP protection and common attack protection
• Intelligent IP bandwidth management and connection limit

TL-NR600-2C-9G-POE is TP-LINK newly developed high-performance PoE · AC integrated Gigabit router products, high-performance network-specific processors, large-capacity high-speed DDRIII memory, support IPsec / PPTP / L2TP VPN, Internet Behavior Management, AP Management, Web Certification, PPPoE Server, IP / MAC Binding, Attack Protection, Bandwidth Management; Built-in AC (Wireless Controller) and 8 Standard PoE (Ethernet Power Supply) function, Unified management of TP-Link AP products and power supply, suitable for enterprises, parks, hotels, etc. to build security, efficient, and easy management.

New hardware architecture, high-speed data forwarding

With a new hardware architecture, a professional dual-core 64-bit network-specific processor, single core closing up to 1GHz, with 512MB DDRIII high-speed memory, packet processing capability is greatly improved. In the actual environment, the typical belt machine is about 300 units.

Multiple VPNs to ensure the security of remote communication

Support IPSec VPN, allow up to 50 tunnels to be established, encrypt confidential data of enterprises and branches, and ensure data security;

It supports PPTP VPN and L2TP VPN server/client mode, and allows up to 32 tunnels (shared) to be established, which is convenient for traveling employees and mobile office workers to remotely access the internal server of the enterprise and realize remote office easily.

Internet behavior management, standardize employee network use

Built-in database of common Internet applications, one-key control of various desktop and mobile Internet applications, including social software / video software / music software / shopping and leisure software / news information software / P2P software / financial software / online games / application store / Basic applications and other categories;

Built-in database of hundreds of URLs in dozens of categories, which can limit employees' access to corresponding websites with one click;

Support prohibiting webpage submission, restrict employees from logging in to various web-based forums, Weibo, emails, etc. to post information, to avoid leakage of sensitive corporate data;

Supports file expansion types, which can easily filter various small files embedded in web pages to prevent viruses, Trojans, etc. from intruding into the corporate network through these small files and jeopardizing network security;

Support behavior auditing function, comprehensively record online behaviors, and output audit results in report form.

VLAN (multiple local area network)

Support IEEE 802.1Q VLAN, enterprises can divide the internal network into different network segments isolated from each other according to their needs, reducing the impact of broadcast storms and viruses;

Support VLAN Layer 3 interface, can realize the IP message forwarding across VLAN, and can set DHCP Server, firewall rules, access authentication strategy and other functions based on VLAN.

A variety of authentication methods to control online access and realize advertising and marketing

Support Web authentication, you can push merchant advertising information through the authentication page;

Support SMS authentication, meet real-name authentication requirements, and conduct secondary marketing based on mobile phone number;

Support PPPoE server, which can realize unified dial-up Internet access for intranet users.

Built-in AC+PoE function, unified management of TP-LINK enterprise AP and power supply

Built-in AC (wireless controller) function, which is both a router and a wireless controller, which can manage up to 50 TP-LINK AP products in a unified manner to form a wireless network;

It can automatically discover the TP-LINK AP in the network, and configure and manage the AP in a unified manner, realize AP zero configuration access, plug and play, and also support AP status monitoring, AP upgrade and scheduled restart, easy maintenance.

All LAN ports support standard PoE power supply and comply with IEEE802.3af/at standards. The maximum output power of a single port is 30W, and the maximum output power of the whole machine is up to 240W; it is suitable for enterprises, parks, hotels, etc. to form a safe, efficient and easy-to-manage network.

Efficient firewall to ensure the security of internal and external networks

Support IP and MAC address binding, effectively prevent internal/external network ARP spoofing; in case of ARP spoofing, it can actively send ARP correction information according to the designated frequency to restore the normal state of the network in time;

Support internal/external network attack protection function, which can effectively prevent various common DoS attacks, scanning attacks, and suspicious packet attacks;

Support MAC address-based filtering function, effectively blocking the access of illegal hosts;

It can assign the authority to pass through the router for various network services, ensure the security of the internal and external networks, support access control rules based on user groups and time periods, and achieve more refined management.

Flexible bandwidth control to ensure reasonable utilization of bandwidth

Supports flexible strategies that enable bandwidth control based on bandwidth utilization, which can perform two-way bandwidth control for each host (IP) in the network, effectively suppressing excessive bandwidth usage by P2P applications such as BT and Thunder, and ensuring that the network is always smooth;

Provide IP-based connection number limit function, which can limit the number of connections of each computer, prevent a small number of users from excessively occupying a large number of connections, and ensure the smooth progress of games, Internet access, chat, video and voice.

Multi-WAN port load balancing and line backup

Provides 1 10/100/1000M fixed WAN port, 5 10/100/1000M fixed LAN ports and 3 10/100/1000M WAN/LAN configurable ports. Users can flexibly configure the number of WAN ports according to actual network requirements to meet Networking requirements for multiple line access;

Supports rich traffic balancing functions such as intelligent routing, special application routing, ISP routing, etc., which can realize bandwidth superposition, make full use of bandwidth resources, and protect user investment;

Support WAN port backup function, can automatically switch to the backup line when the main line fails to ensure the normal operation of the network.

More useful features

Support DDNS and virtual server function, easily build intranet server and private website;

Support UPnP and ALG service functions to ensure that special network applications smoothly penetrate NAT;

The new all-Chinese WEB management interface makes management and maintenance more convenient and quick;

Provide log list function to record the network running status in detail;

Support Ping, Tracert and other fault detection tools to help quickly find and eliminate network faults.
