TP-LINK TL-ER6225G industrial grade Gigabit Router 5 ports with machine capacity 1000 manage 200 APs
Brand: TP-LINK
Model: TL-ER6225G-INDUSTRIAL
Dimensions: 137mm x 128mm x 65.40mm
Provide 5 10/100/1000M adaptive RJ45 ports and 2 Gigabit SFP ports (combo) Provide a USB 3.0 interface Industrial grade working temperature: -40℃~75℃ Wide voltage input: 9.6V~60VDC Multiple installation methods: rail installation + wall installation IP30 protection: reduce the impact of dust Provide a rich security strategy Support cloud management, convenient operation and maintenance Three-way power input, redundant backup, greatly improve the product power supply reliability EMS high protection level, without fear of various harsh environments *Industrial routers are not equipped with power supply, please purchase separately if you need to use the power supply Protocol standard IEEE 802.3,802.3i,802.3u,802.3x,802.3ab,802.3z Port shape 5 10/100/1000MRJ45 ports 2 Gigabit SFP ports
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Protocol standard | IEEE 802.3,802.3i,802.3u,802.3x,802.3ab,802.3z |
| Port shape | 5 10/100/1000MRJ45 ports 2 Gigabit SFP ports (combo) 1 USB 3.0 port |
| Indicator light | 5 RJ45 status indicators Link/ACT 2 SFP status indicators Link/ACT 1 USB status indicator PWR1, PWR2, PWR3 SYS/FAULIT |
| power input | DC input voltage 12/24/48 VDC (9.6~ 60 VDC) input current 1.1A@24VDC supports reverse connection protection |
| DIP | Support port interrupt alarm |
| structure | IP30 protection grade Product size 137mm*128mm*65.4mm rail/wall mounting |
| temperature | Working temperature -40°C — 75°C Storage temperature ‒40°C — 85°C |
| humidity | Operating humidity 10%RH — 90%RH, non-condensing Storage humidity 5%RH — 90%RH, non-condensing |
| Certification Standards_EMS | IEC/EN 61000-4-2,Level 3 IEC/EN 61000-4-3,Level 4 IEC/EN 61000-4-4,Level 4 IEC/EN 61000-4-5,Level 3 IEC/EN 61000-4-6,Level 3 IEC/EN 61000-4-8,Level 5 IEC/EN 61000-4-9,Level 5 IEC/EN 61000-4-10,Level 5 |
| Network protocol | TCP/IP、DHCP、ICMP、NAT、PPPoE、SNTP、HTTP、DNS、H.323、SIP、DDNS |
| basic settings | Interface setting DHCP server |
| AP management | AP settings, manage up to 200 APs Wireless network settings Wireless client status |
| Access method | Dynamic IP, static IP, PPPoE, L2TP, PPTP |
| Transmission control | NAPT one-to-one NAT mapping virtual server FTP ALG, H.323 ALG, SIP ALG, PPTP ALG IP bandwidth control, connection number control, flow/connection number monitoring Maximum concurrent connections: 300,000 intelligent balances, special application routing, ISP routing, line backup static routing, policy routing, system routing list |
| ARP protection | Support ARP scanning, ARP list, free GARP, support IP MAC binding |
| Attack protection | Anti-DoS, scanning, suspicious packet and other common attacks |
| Access control | Support setting MAC address filtering black and white list access control list |
| Behavior control | Social software/Video software/Music software/Shopping and leisure software/News software/P2P software/Financial software/Online games/App store/Basic applications and other common applications Limit QQ black and white list URL filtering Web page security (Prohibit page submission, filtering Specify the file extension type) Application signature database upgrade |
| VPN | IPsec VPN (200 tunnels) PPTP/L2TP VPN (200 tunnels) |
| Certification Management | Web authentication, support local authentication, Radius authentication, one-click Internet access, to meet a variety of authentication needs Customize authentication page, easily push text and image ads, carry out marketing promotion Authentication-free strategy |
| system service | Dynamic DNS (Peanut Shell, Comay, 3322) UPnP service DNS proxy |
| Management and maintenance | Chinese Web network management, remote management configuration backup and import configuration system software upgrade interface traffic statistics, IP traffic statistics ping, tracert diagnostic tool system log |
| Cloud management | TP-LINK commercial network cloud platform TP-LINK local NMS management platform Terminal Internet strategy |
| Packaging accessories | Industrial Router TL-ER6225G Industrial Grade Warranty Card User Manual Serial Cable Ground Wire |
