TP-LINK TL-ER6160T 10 Gigabit Enterprise Router

Brand: TP-LINK

Model: TL-ER6160T

Dimensions: 227mm x 440mm x 44mm

Quad-core CPU, 512MB DDRIV high-speed memory, strong performance 2 10 Gigabit SFP+ optical fiber expansion ports, 4 10/100/1000M RJ45 electrical ports, customizable port types IPSec/PPTP/L2TP VPN, remote communication is more secure Web authentication, SMS authentication, PPPoE server Online behavior management (application restriction / website filtering / web security) Load balancing and line backup Internal and external network ARP protection and common attack protection Intelligent IP bandwidth management and connection limit port

2 10G SFP+ optical fiber module expansion ports
4 10/100/1000M custom RJ45 ports
1 USB 3.0 storage port
1 Micro SD card slot
1 Console port

processor

Quad-core 64-bit ARM processor, single-core

Product Features

Quad-core CPU, 512MB DDRIV high-speed memory, strong performance
2 10 Gigabit SFP+ optical fiber expansion ports, 4 10/100/1000M RJ45 electrical ports, customizable port types
IPSec/PPTP/L2TP VPN, remote communication is more secure
Web authentication, SMS authentication, PPPoE server
Online behavior management (application restriction / website filtering / web security)
Load balancing and line backup
Internal and external network ARP protection and common attack protection
Intelligent IP bandwidth management and connection limit

Technical Specifications

Property Description	Property Value
port	2 10G SFP+ optical fiber module expansion ports 4 10/100/1000M custom RJ45 ports 1 USB 3.0 storage port 1 Micro SD card slot 1 Console port
processor	Quad-core 64-bit ARM processor, single-core clocked at 1.4GHz
RAM	DDRIV 512MB
FLASH	32MB NOR+128MB NAND
Indicator light	Port: Link/Act, Speed, USB, Micro SD Device: PWR, SYS
Dimensions	440(w)x227(D)x44(H) mm
Input power	100~240V AC,50/60Hz
Cooling method	Natural heat dissipation
Use environment	operating temperature: 0°C ~ 40°C, Working humidity: 10% ~ 90% RH does not condense storage temperature: -40°C ~ 70°C, storage humidity: 5% ~ 90 % RH does not condense
Typical belt load	2000 sets
Network protocol	TCP/IP、DHCP、ICMP、NAT、PPPoE、SNTP、HTTP、DNS、H.323、SIP、DDNS
basic settings	interface setting DHCP server MAC address setting VLAN (multi-LAN) switch settings DNS agent
AP management	AP setting, managed to manage 300 TP-LINK AP wireless network settings wireless client status
Transmission control	One-to-one NAT, NAPT, virtual server, ALG, NAT-DMZ IP bandwidth control, connection control, traffic/connection monitoring Maximum Number of concurrent connections: 600,000 intelligent balancing, ISP routing, special application routing, online detection, line backup policy routing, static routing
Safety management	supports ARP scan, ARP list, GARP support IP / MAC binding anti-DOS class, scan class, suspicious package class, etc. Support Set MAC Address Filter Black and White List Access Control List
ARP protection	support ARP scan, ARP list, free GARP support IP Mac binding
Behavior control	Social Software / Video Software / Music Software / Shopping Leisure Software / News Software / P2P Software / Financial Software / Network Game / App Store / Fundamental Application Limits QQ black and white list URL packet filtering, URL filter web security (forbidden web file submission, various file types in the filter page) behavior audit Application Characteristic Library Update
VPN	IPsec VPN (200 Tunnel) PPTP / L2TP VPN (200 Tunnel)
Access authentication	Web authentication, supports local authentication, Radius authentication, and one-click Internet access, meeting various authentication needs QQ black and white list SMS authentication, meeting real-name authentication requirements, and can be performed based on mobile phone numbers Secondary marketing certification-free strategy
system service	PPPoE server, with a capacity of 2000 Dynamic DNS (peanut shell, Komai, 3322) UPnP service
Management and maintenance	Chinese Web Network Management, Remote Management Configuration Backup and Import Configuration System Software Upgrade Interface Traffic Statistics, IP Traffic Statistics ping, Tracert Diagnostic Tool Time Setting System Log
San Dick	memory 64G and 128G, performance parameters U3, V30, Class10
Kingston	memory 64G and 128G, performance parameters U1, A1, V10, Class10
Samsung	memory 64G and 128G, performance parameters U1, Class10
Toshiba	memory 64G and 128G, performance parameters U1, Class10
