TP-LINK TL-SG2005P 5-port full gigabit web managed PoE switch 1GE 4PoE 57W

Brand: TP-LINK

Model: TL-SG2005P

Dimensions: 100mm x 98mm x 25mm

5 10/100/1000Base-T RJ45 ports 1 to 4 thousand megabytes RJ45 port support IEEE 802.3af/at standard PoE power supply The maximum PoE power supply of the whole machine is 60W, and the maximum PoE power supply of a single port is 30W Support Business Cloud APP and web-side remote management Support intelligent start, abnormal alarm, fast discharge Support 802.1Q VLAN, Port VLAN, QoS, bandwidth control, storm suppression Support port aggregation, port traffic statistics, port monitoring, cable detection, loop protection Support cloud management, VLAN isolation, standard exchange three working modes * This model is only 3.0 and above supports cloud management functions Product model TL-SG2226P TL-SG2218P TL-SG2210P TL-SG2005P Gigabit RJ45 port 24 16 9 5 Gigabit SFP port 2 2 1 0 PoE port 24 16

Product Features

5 10/100/1000Base-T RJ45 ports
1 to 4 thousand megabytes RJ45 port support IEEE 802.3af/at standard PoE power supply
The maximum PoE power supply of the whole machine is 60W, and the maximum PoE power supply of a single port is 30W
Support Business Cloud APP and web-side remote management
Support intelligent start, abnormal alarm, fast discharge
Support 802.1Q VLAN, Port VLAN, QoS, bandwidth control, storm suppression
Support port aggregation, port traffic statistics, port monitoring, cable detection, loop protection
Support cloud management, VLAN isolation, standard exchange three working modes
* This model is only 3.0 and above supports cloud management functions

Product model	TL-SG2226P	TL-SG2218P	TL-SG2210P	TL-SG2005P
Gigabit RJ45 port	24	16	9	5
Gigabit SFP port	2	2	1	0
PoE port	24	16	8	4
Maximum PoE output power of the whole machine	225W	180W	57W	60W
Maximum power consumption of the whole machine	263W	213W	68W	65W
Maximum PoE output power of the port	30W
PoE power supply standard	IEEE 802.3af/at
MAC address capacity	8K	8K	4K	2K
Mode switch	Support cloud management, VLAN isolation, standard exchange three working modes
Network management functions	Support remote management through Shangyun APP and Shangyun network cloud platform (Web terminal) Support local web management Support 802.1Q VLAN, MTU VLAN, port VLAN Support to configure port flow control, duplex, on/off Support port aggregation, port monitoring, port isolation, port traffic statistics Support DHCP Snooping (except 5/8 port models) Support QoS, port egress/ingress speed limit, storm suppression Support cable detection, loopback detection
Business cloud function	Support quick start Support device information reporting Support alarm push Support equipment remote operation and maintenance
Shell size (mm)	44018044	29418044	1719827	1009825
Input power	220VAC, 50Hz	220VAC, 50Hz	53.5VDC/1.22A	53.5VDC/1.22A
Use environment	Work temperature: 0°C ~ 40°C Storage temperature: -40℃~70℃ Working humidity: 10% ~ 90% RH without condensation Storage humidity: 5% to 90% RH without condensation

Technical Specifications

Property Description	Property Value
Gigabit RJ45 port	5
PoE port	4
Maximum PoE output power of the whole machine	57W
Maximum power consumption of the whole machine	65W
Maximum PoE output power of the port	30W
PoE power supply standard	IEEE 802.3af/at
MAC address capacity	2K
Mode switch	Support three working modes: Web management, VLAN isolation, standard switching
Network management functions	Support management via Web page Support 802.1Q VLAN, MTU VLAN, port VLAN Support QoS, bandwidth control, storm suppression Support port aggregation, port mirroring, port monitoring Support bandwidth control, storm suppression Support cable detection, loopback detection
Shell size (mm)	1009825
Input power	53.5VDC/1.13A
Use environment	Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90% RH non-condensing Storage humidity: 5%~90% RH non-condensing
