TP-LINK TL-POE10R Standard PoE splitter 1 gigabit PoE port 1 gigabit port 1DC power port
Complies with IEEE 802.3af standard Provides 5V/9V/12VDC third gear output Maximum transmission distance up to 100 meters Gigabit Ethernet port Plug and play, no management required TL-POE10R is a PoE separator that is autonomously developed by TP-Link, which is in line with the IEEE 802.3af standard, which can be separated from the data signal transmission through the network cable. TL-POE10R is used in conjunction with IEEE 802.3af standards (such as TP-LINK TL-POE150S, TL-SF1008P, TL-SG3424P, etc.) to provide data and power supplies simultaneous network devices that do not support PoE. TL-POE10R can output 5V / 9V / 12V three-speed voltage, with power supply equipment, can be flexible to expand home networks, office networks without the need to be limited by power line layout.
Product Features
TL-POE10R is a PoE separator that is autonomously developed by TP-Link, which is in line with the IEEE 802.3af standard, which can be separated from the data signal transmission through the network cable. TL-POE10R is used in conjunction with IEEE 802.3af standards (such as TP-LINK TL-POE150S, TL-SF1008P, TL-SG3424P, etc.) to provide data and power supplies simultaneous network devices that do not support PoE. TL-POE10R can output 5V / 9V / 12V three-speed voltage, with power supply equipment, can be flexible to expand home networks, office networks without the need to be limited by power line layout. |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Supported standards | IEEE 802.3, 802.3u, IEEE802.3ab,IEEE802.3af CSMA/CD, TCP/IP |
| port | LAN port: 1 10/100M/1000M adaptive RJ45 port PoE port: 1 10/100M/1000M adaptive RJ45 port |
| basic skills | Compatible with IEEE802.3af standard power receiving equipment 12VDC/9VDC/5VDC three-speed output Maximum transmission distance is 100m Gigabit Ethernet port Plug and play, no management required |
| LED indicator | PWR |
| Output Power | 12W (12VDC) /10W (5VDC)/9W(9VDC) |
| size | 80.8mm*54mm*24mm(W*D*H) |
| Use environment | Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing |
