AXIS TU8011 4-port PoE Extender - User Manual Setup Guide

Power output options Troubleshooting LED indicators POWER ON STATUS Color State Indication Green Solid Internal power converter on and ready to apply power to output ports Green Flashing Internal power converter in light load condition LINK : link speed Color State Indication Amber Solid 100M/1000M link speed Amber Off 10M link speed ACT : activity Color State Indication Green Solid/flashing Data transmission in progress PoE PSE POWER IN Color State Indication Green Solid Power over Ethernet (PoE) 802.3bt Type 4 Class 8 power sourcing equipment connected PoE STATUS Color State Indication Green Solid Valid Power over Ethernet (PoE) IEEE 802.3af/at PD detected Green Flashing Standing by Red Solid Overload/overcurrent detected Red Flashing Invalid Power over Ethernet (PoE) IEEE 802.3af/at PD

Power output options

Troubleshooting

LED indicators

POWER ON STATUS
Color	State	Indication
Green	Solid	Internal power converter on and ready to apply power to output ports
Green	Flashing	Internal power converter in light load condition

LINK: link speed
Color	State	Indication
Amber	Solid	100M/1000M link speed
Amber	Off	10M link speed

ACT: activity

Color

State

Indication

Green

Solid/flashing

Data transmission in progress

PoE PSE POWER IN
Color	State	Indication
Green	Solid	Power over Ethernet (PoE) 802.3bt Type 4 Class 8 power sourcing equipment connected

PoE STATUS
Color	State	Indication
Green	Solid	Valid Power over Ethernet (PoE) IEEE 802.3af/at PD detected
Green	Flashing	Standing by
Red	Solid	Overload/overcurrent detected
Red	Flashing	Invalid Power over Ethernet (PoE) IEEE 802.3af/at PD detected

Technical issues, clues, and solutions

Problems turning on the camera
Compatibility issue	Make sure the camera is compatible with the PoE extender. For a list of compatible products, see the PoE extender’s product page at
LLDP protocol	Turn off LLDP. In the camera’s web interface, go to System > Plain config, select group Network, and clear LLDP Send Max PoE.
